Product Details:
Payment & Shipping Terms:
|
| Material: | 17-7PH, UNS S17700 | Product: | 17-7PH Stainless Steel Sheet, Strip |
|---|---|---|---|
| Specification: | AMS 5529 | Delivery Condition: | Solution Heat Treated, Condition C ( As Cold Rolled ) |
| Highlight: | hardening Stainless Steel Sheet Strip,17-7PH Precipitation Hardening Stainless Steel,Solution heat treated Hardening Stainless Steel |
||
17-7PH Stainless Steel Sheet And Strip UNS S17700 AMS-5529
Stainless steel, corroion resistant, sheet and strip 17Cr - 7.1Ni - 1.1Al
Solution heat treated, and cold rolled, precipitation hardenable, material 17-7PH, UNS S17700
17-7PH Material typically for parts such as springs requiring corroion resistance, and high strength up to 316℃.
Chemical composition %
| Carbon | Si | Mn | P | S | Cr | Ni | Al |
| 0.09 | 1.00 | 1.00 | 0.040 | 0.030 | 16.00~18.00 | 6.5~7.75 | 0.75~1.50 |
Product form
Sheet and strip 17-7PH
Material in solution heat treated, or as cold rolled, condition C
Tensile properties, condition C, min. tensile properities
| Property | Value |
| Tensile strength | 1379 Mpa |
| Yield strength at 0.2% offset | 1207 Mpa |
| Elongation in 2 inches | 1% |
After precipitation heat treatment condition CH900
Min. tensile properties as precipitation heat treated to CH900 condition
| Property | Value |
| Tensile strength | 1655 Mpa |
| Yield strength at 0.2% offset | 1586 Mpa |
| Elongation in 2 inches | 1% |
For Details, please Contact
WUXI GUANGLU Special Steel Co., Ltd.
Stainless martensitic • precipitation hardening steel • stainless ferritic — Our answer to your needs
