AMS 5520 PH15-7Mo UNS S15700 Stainless Steel Strip In Coil And 1.4532 Plate
PH 15-7Mo is a semi-austenitic precipitation-hardening stainless steel that provides high strength
and hardness, good corrosion resistance and minimum distortion on heat treatment.
It is easily formed in the annealed condition and develops an effective balance of properties by simple
heat treatments. For applications requiring exceptionally high strength, cold-reduced PH 15-7Mo
Stainless Steel in Condition CH 900 is particularly useful for applications permitting
limited ductility and workability. This alloy is particularly beneficial for a wide range of applications
that include retaining rings, springs, diaphragms, aircraft bulkheads, welded and brazed honeycomb
paneling and other aircraft components requiring high strength at elevated temperatures.
Standard
| JIS | EN, DIN | AISI, ASTM |
| SUS632 | 1.4568, X7CrNiAl17-7 | PH 15-7Mo, S15700 |
Chemical composition wt%
| C | Si | Mn | P | S | Cr | Ni | Mo | Al |
| 0.09 | 1.00 | 1.00 | 0.040 | 0.040 | 14.0~16.0 | 6.5~7.75 | 2.0~3.0 | 0.75~1.50 |
Product forms
PH15-7Mo stainless steel strip coil and sheet
Material is supplied in Condition A, ready for fabrication by the user. Sheet and strip.
material 1.27mm and thinner are also produced in the hard-rolled Condition C for applications
requiring maximum strength.
