| Ferritic Grade: | AISI 430, EN 1.4016, DIN X6Cr17, JIS SUS430 | Product: | Stainless Steel Sheet / Plate / Coil AISI 430 |
|---|---|---|---|
| Size: | 3.0~15.0*1250/1500mm | Delivery State: | Annealed |
| Surface: | Hot Rolled, 1D | Service: | Slitting, Cut To Lengths |
| Highlight: | 420 stainless steel plate,1.4028 stainless steel |
||
AISI 430 / 1.4016 is a classic 16% chromium ferritic stainless steel. Good corrosion resistance in mildly
corrosive environments combined with good formability have made this product one of the most used
non-hardenable ferritics, especially in indoor environments.
Typical applications
Chemical composition ( weight % )
| Grade | C | Si | Mn | P | S | Cr | Mo |
| 430 | 0.12 max | 1.00 max | 1.00 max | 0.040 max | 0.030 max | 16.00- 18.00 | - |
Mechanical properities
| Grade | Hardness | Yield Strength ( MPa ) | Tension Strength ( MPa ) | Elongation ( % ) | HV |
| 430 | ANN | ≥205 | ≥420 | ≥22 | ≤200 |
| 1/4H | ≥500 | ≥550 | ≥5 | 160- 200 | |
| 1/2H | ≥600 | ≥650 | ≥3 | 200- 240 | |
| 3/4H | ≥680 | ≥750 | ≥2 | 240- 280 | |
| H | ≥800 | ≥850 | ≥1 | ≥280 |
Cold rolled stainless precision steel strip coil 430, hardness in ANN, 1/4H, 1/2H, 3/4H, H delivery state.
