| Material: | 17-7PH , 631 | Size: | 0.2~16.0mm, Others On Request |
|---|---|---|---|
| Delivery State: | Condition C | Form Of Supply: | Stainless Steel Wire In Coil Or Cut Lengthsr Rod, Round Bar |
| Highlight: | stainless steel spring wire,stainless steel coil wire |
||
17-7PH 631 1.4568 Cold Drawn Stainless Steel Wire Round Bar
17-7 PH stainless steel is a precipitation hardened stainless steel that provides high strength and
hardness, excellent fatigue properties, good corrosion resistance, good formability, and minimum
distortion upon heat treatment.
In high-heat treated conditions, 17-7PH stainless steel possesses excellent mechanical properties.
The 17-7PH alloy provides valuable property combinations particularly well suited for aerospace applications.
This special alloy 17-7PH stainless also provides benefits for other applications requiring high strength
and good corrosion resistance - with excellent properties at temperatures up to 600° F.
17-7 PH Stainless Steel delivered in Condition A and Condition C.
17-7 Stainless Steel requires 3 steps in heat treating including austenite conditioning, cooling to
transform the austenite to martensite, and precipitation hardening (for Condition TH & RH).
Analysis ( weight % )
|
Grade |
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Al |
|
17-7PH |
0.09 max |
1.00 max |
1.00 max |
0.040 |
0.030 |
16.00~18.00 |
6.5~7.75 |
0.75~1.50 |
Applications of 17-7 Stainless Steel
Variety Of Springs And Washers
Aerospace Parts
Heat Exchangers
Power Boilers
High Strength/ High Temperature Conditions
Chemical Processing Equipment
Product forms
17-7 PH, SUS631, EN 1.4568, DIN X7CrNiAl17-7 cold drawn stainless steel wire, rod
