| PH Grade: | 17-7PH, SUS631, UNS S17700 | Product: | 631 Stainless Steel Strip, Coil, Sheet |
|---|---|---|---|
| Size Range: | 0.1~10.0X420mm | Delivery Condition: | Annealed, C |
| Highlight: | 17-7PH Strip,3/4H Condition Steel Coil,SUS631-CSP Coil |
||
SUS631-CSP Cold Rolled Stainless Steel Coil 17-7PH Strip Condition C
SUS631 stainless steel provides valuable property combinations particularly well suited for aerospace applications.
17-7PH, SUS631 stainless also provides benefits for other applications requiring formability,
high strength and good corrosion resistance, as well as excellent properties for flat springs, bellville washers,
eyelets, and strain gauges at temperatures up to 600°F (316°C).
Characteristics
Chemical composition %
| C | Si | Mn | P | S | Cr | Ni | Al |
| 0.09 | 1.00 | 1.00 | 0.040 | 0.030 | 16.00~18.00 | 6.50~7.75 | 0.75~1.50 |
Forms of supply
SUS631-CSP Stainless Steel sheet and strip, coil.
Material is supplied in Condition A, ready for fabrication by the user.
Sheet and strip are also produced in the hard-rolled Condition C for applications requiring maximum strength.
JIS G4313 cold rolled stainless steel strip for springs
| Condition | Hardness HV |
| Solution annealed | 200 max. |
| 1/2H | 350 min. |
| 3/4H | 400 min. |
| H | 450 min. |
