| Ferritic Grade: | AISI 409 EN 1.4512 Stainless Steel | Product: | AISI 409 EN 1.4512 Stainless Steel Sheet , Plate And Slit Strip In Coil |
|---|---|---|---|
| Size: | 0.3~10.0X1250/1500mm | Delivery State: | Annealed |
| Surface: | 2D, 2B, 1D | ||
| Highlight: | stainless strip steel,1.4028 stainless steel |
||
AISI 409 EN 1.4512 Stainless Steel Sheet, Plate And Slit Strip In Coil
409 is a low cost ferritic stainless steel. Its dominant use is in vehicle exhaust systems, so much so that
it is often referred to as “muffler” grade.
| Grade | C | Cr | Ni | Ti |
| 409 | 0.03 | 10.5~11.7 | 0.50 | 8(C+N) min. 0.15~0.50 |
This 409 stainless grade combines the following characteristics:
Automotive exhaust systems have to withstand aggressive conditions from high temperatures
at the manifold end, sulphuric acid condensate and de-icing salt. Given the severity of these conditions,
it can seem surprising that the 11% Cr 409 grade has met the challenge for many years.
Exhaust components are also required to be bent, expanded and pressed into all sorts of convoluted shapes.
The ability of a ferritic steel to meet these formability requirements is little short of amazing.
Other applications include:
Heat exchangers, gas boilers, fuel filters.
