Cold Rolled Spring Stainless Steel Strip ( Coil ) 316CSP and 316LCSP
Austenitic stainless steel. A grade of steel offering superior corrosion resistance and particularly effective
against stress corrosion cracking and intergranular corrosion created by increasing the nickel (Ni) content of
SUS 304 stainless and further adding molybdenum (Mo).
As there is no JIS standard specifically covering 316 and 316 L-CSP, the 316 and 316 L-CSP carried is
created in conformation with the standard for 304 CSP.(The "L" in SUS 316 L stands for "low carbon.")
Please note that although in a solution treated state it is not magnetic, once it is CSP it is weakly magnetic.
Typical applications
Diaphragms, bellows, components used around water, washers etc.
Chemical composition ( weight % )
Grade | C | Si | Mn | P | S | Cr | Ni | Mo |
316 | 0.08 max | 1.00 max | 2.00 max | 0.045 max | 0.030 max | 16.00~18.00 | 10.00~14.00 | 2.00~3.00 |
316L | 0.03 max | 1.00 max | 2.00 max | 0.045 max | 0.030 max | 16.00~18.00 | 12.00~15.00 | 2.00~3.00 |
Product forms
Cold Rolled Spring Stainless Steel Strip (Coil) 316-SCP, 316L-CSP
Mechanical properities
Grade | As rolled | ||
HV | Tensile strength | Elongation | |
316-CSP | 310 min. | 930 min. | 3 min. |
316L-CSP | 250 min. | 780 min. | 6 min. |
We offer small quantities with short delivery times.
Wuxi Guanglu Special Steel Co., Ltd. – your productivity partner for precision strip steel.
