Product Details:
Payment & Shipping Terms:
|
| Material: | EN 1.4313 DIN X3CrNiMo13-4 UNS S41500 | Product: | DIN 1.4313 Hot Rolled Stainless Steel Plates |
|---|---|---|---|
| Size Range: | 8~150X3300mm | Delivery Condition: | Annealed |
| Surface Finish: | Black, Pickled 1D | Specification: | DIN EN 10088-2 |
| High Light: | EN 1.4313 Stainless Steel Plates,UNS S41500 Stainless Steel Plates,150X3300mm Stainless Steel Plates |
||
EN 1.4313 Hot Rolled Stainless Steel Plates UNS S41500 DIN X3CrNiMo13-4
Grade EN 1.4313, DIN X3CrNiMo13-4, ASTM / ASME UNS S41500 is a 13% Cr-4% Ni-0.5% Mo martensitic stainless steel.
Its nickel content, associated with low carbon ensures better weldability, ductility, impact and fatigue resistance than
13 Cr martensitic grades (410, 420).
The alloy has good corrosion resistance to fresh water and performs well in abrasive conditions.
It combines high mechanical properties, excellent toughness and weldability.
It is commonly used in turbines and flow control systems in the hydropower industries.
Chemical composition % weight
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | N |
| 1.4313 | 0.05 | 0.70 | 1.50 | 0.040 | 0.015 | 12.00~14.00 | 3.5~4.5 | 0.3~0.7 | 0.02 min. |
Typical application
1.4313 stainless grade is specially designed for applications requiring high strength, high toughness and
medium corrosion resistance properties.
The chromium, nickel and molybdenum additions make the alloy resistant to corrosion in fresh water.
Typical applications are hydroelectric turbines and systems (blades, runners, gates, rings, shield plates,…),
hydropter wings to fight cavitation by high speed water.
Forms of supply
EN 1.4313, DIN X3CrNiMo13-4, AISI F6NM, UNS S41500 stainless available in forms of
hot rolled stainless steel plates, round bars, forgings
