| Precipitation Hardening Steel: | SUS631 17-7PH | Product: | 631 Stainless Steel Strip |
|---|---|---|---|
| Size Range: | 0.1~3.0X420mm | Delivery Condition: | A, C |
| High Light: | stainless steel precision strip,stainless steel foil |
||
SUS631 Cold Rolled Stainless Steel Strip And Sheet Plate 17-7PH
Precipitation Hardened High Strength Stainless Steel SUS631, 17-7PH, ASTM 631, EN 1.4568, DIN X7CrNiAl17-7, SS 2388
Typical applications
springs and parts with very complicated forms e.g. hinges, couplings, washers, and thermostats.
Chemical composition % typical value
| C | Si | Mn | P | S | Cr | Ni | Al |
| 0.08 | 0.3 | 0.9 | 0.025 | 0.005 | 16.3 | 7.2 | 1.0 |
Forms of supply
17-7 PH Stainless Steel sheet and strip.
Material is supplied in Condition A, ready for fabrication by the user.
Sheet and strip material are also produced in the hardrolled Condition C for applications requiring maximum strength.
STANDARD HEAT TREATMENTS
This material requires three essential steps in heat treating:
1) Austenite conditioning.
2) Cooling to transform the austenite
2) to martensite.
3) Precipitation hardening to
2) Condition TH 1050 or RH 950.
To obtain the highest mechanical properties from the alloy, Condition A material is transformed to martensite at
the mill by cold reduction to Condition C. Hardening to Condition CH 900 is accomplished with a single,
low-temperature heat treatment.
SPECIFICATIONS
AMS 5528 Sheet, Strip and Plate
AMS 5529 Sheet and Strip–Cold Rolled
MIL-S-25043 Plate, Sheet and Strip
ASTM A 693 Plate, Sheet and Strip
(Listed as Grade 631-UNS S17700)
JIS G4313 Cold rolled stainless steel strip for springs
EN 10151 Stainless steel strip for springs
