Product Details:
Payment & Shipping Terms:
|
| Precipitation Hardening Steel: | SUS631 | Product: | Cold Rolled Stainless Steel Strip Coil SUS631-CSP |
|---|---|---|---|
| Size: | 0.1~3.0X3~420mm | Delivery Condition: | Solution Treated, 1/2H, 3/4H, H |
| Form Of Supply: | SUS631 Stainless Steel Strip, Coil, And Sheet | Specification: | JIS G4313 Cold Rolled Stainless Steel Strip For Springs |
| High Light: | 630 stainless steel,17 7 ph stainless steel |
||
Cold Rolled Stainless Steel Coil Grade JIS SUS631-CSP 1/2H 3/4H H
Precipitation hardening steel JIS SUS631, 17-7PH, UNS S17700, EN 1.4568, DIN X7CrNiAl17-7
is a semi-austenitic stainless steel which is austenitic in the annealed condition, but martensitic in
the hardened condition. Type 631 provides high strength and hardness, excellent fatigue properties,
good corrosion resistance and minimum distortion upon heat treatment.
It is easily formed in the annealed condition, then hardened to high strength levels by simple heat
treatments to Conditions RH 950 and TH 1050.
The exceptionally high strength of Condition CH 900 offers many advantages where limited ductility
and workability are permissible. In its heat treated condition, this alloy provides exceptional mechanical
properties at temperatures up to 900 °F (482 °C).
Chemistry typical
| C | Si | Mn | P | S | Cr | Ni | Al |
| 0.09 max | 1.00 max | 1.00 max | 0.040 max | 0.030 max | 16.00~18.00 | 6.50~7.75 | 0.75~1.50 |
Applications
Springs, Washers, Clips, Surgical parts, Blades, Bellows, Honeycomb
Forms
Stainless steel shim SUS631 17-7PH coil / strip / sheet
Standard JIS G4313 Cold rolled stainless steel strip for springs
| Grade | Finish | As cold rolled, or either as solution treated or as annealed | As precipitataion hardened | ||
| Hardness HV | Bendability | Symbol of heat treatment | Hardness | ||
| SUS301-CSP | 1/2H | ≧310 | ≦Twice of the thickness | - | - |
| 3/4H | ≧370 | ≦2.5 times of the thickness | - | - | |
| H | ≧430 | - | - | - | |
| EH | ≧490 | - | - | - | |
| SEH(1) | ≧530 | - | - | - | |
| SUS304-CSP | 1/2H | ≧250 | ≦Twice of the thickness | - | - |
| 3/4H | ≧310 | ≦2.5 times of the thickness | - | - | |
| H | ≧370 | - | - | - | |
| SUS631-CSP | 0 | ≧200 | ≦0.5 times of the thickness | TH1050 RH950 |
≧345 ≧392 |
| 1/2H | ≧350 | ≦1.5 times of the thickness | CH | ≧380 | |
| 3/4H | ≧400 | - | CH | ≧450 | |
| H | ≧450 | - | CH | ≧530 | |
