| Material: | Mat.No. 1.4922 DIN X20CrMoV11-1 Stainless Steel Sheet And Plate | Size Range: | 0.1~60.0x300mm |
|---|---|---|---|
| Delivery State: | Annealed | Characteristic: | High Temperature Resistant |
| High Light: | stainless strip steel,1.4028 stainless steel |
||
Mat No. 1.4922 DIN X20CrMoV11-1 Stainless Steel Sheet And Plate
1.4922 is creep-resistant material that is generally used for temperatures up to 650oC.
Component parts for steam turbines and other components, resistive to compressed hydrogen for chemical industry.
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | V |
| 1.4922 | 0.18~0.24 | 0.50 max | 0.40~0.90 | 0.025 max | 0.015 max | 11.00~12.50 | 0.30~0.80 | 0.80~1.20 | 0.25~0.35 |
Hardening
Harden from a temperature of 1020-1070oC followed by air or oil quenching. Structure is martensite.
Tempering
Tempering temperature: 720-780oC.
Form of supply
EN 1.4922 DIN X20CrMoV11-1 Stainless sheet, plate, coil and strip
