Product Details:
Payment & Shipping Terms:
|
| Material: | 15-5PH, EN 1.4545, DIN X5CrNiCu15-5 | Product: | 15-5PH Stainless Steel Bars |
|---|---|---|---|
| Dia: | 3.0~450mm | Surface: | Black, Peeled, Polished, Ground |
| High Light: | stainless steel round bar,1.4313 stainless steel |
||
15-5PH is a variant of the older 17-4PH chromium-nickel-copper precipitation hardening stainless steel.
Both alloys exhibit high strength and moderate corrosion resistance.
High strength is maintained to approximately 600 degrees F.
The 15-5PH alloy was designed to have greater toughness than 17-4PH.
This improved toughness is achieved by reduced delta ferrite content and control of inclusion size and shape.
Applications:
Chemical composition ( weight % )
| Grade | C | Si | Mn | P | S | Cr | Ni | Cu | Nb |
| 15-5PH | 0.07 max | 1.00 max | 1.00 max | 0.040 max | 0.030 max | 14.0~15.5 | 3.5~5.5 | 2.5~4.5 | 0.15~0.45 |
| A | H900 | H925 | H1025 | H1075 | H1150 | H1150-M | |
| Tensile strength | 1103 | 1379 | 1310 | 1172 | 1138 | 1034 | 945 |
| Yield strength | 793 | 1275 | 1207 | 1138 | 1103 | 896 | 765 |
| Elongation, % in 2''% | 5 | 9 | 9 | 10 | 11 | 12 | 17 |
| Rockwell hardness | 35 | 45 | 43 | 38 | 37 | 33 | 31 |
