Automotive Ferritic Stainless Steel Sheet Plate AISI 436 EN 1.4526 DIN X6CrMoNb17-1
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Material: | AISI 436 , EN 1.4526 , DIN X6CrMoNb17-1 Ferritic Stainless Steel Sheet And Plate | Cold Rolled Size: | 0.3~3.0*1250mm |
|---|---|---|---|
| Hot Rolled Size: | 3.0~60.0*1250/1500mm | Delivery State: | Annealed |
| Surface: | 2B, 2D, 1D | Edge: | Mill, Cut Edge |
| Service: | Coil Slitting, Cut Lengths On Request | Product Name: | Ferritic Stainless Steel |
AISI 436 , EN 1.4526 , DIN X6CrMoNb17-1 ferritic stainless steel sheet and plate
Grade 436 is a 1% molybdenum-alloyed ferritic stainless steel with medium chromium content.
It is suitable for use in many corrosive environments, like for instance in the cold end of automotive
exhaust systems. Because of its titanium alloying, 436 stainless can be welded in all dimensions without becoming susceptible to intergranular corrosion.
Type 436 is a variation of Type 434 to which Columbium has been added to minimize "roping" or "ridging" during stretch forming operations.
Typical applications
- Automotive exhaust systems & mufflers
- Decorative trim in automotive applications
Chemical composition of stainless 436
| Grade | C | Si | Mn | P | S | Cr | Mo | Nb |
| 436 | 0.12 | 1.00 | 1.00 | 0.040 | 0.030 | 16.00~18.00 | 0.75~1.25 | 5XC min, 0.80 max |
Typical mechanical properties
| Tensile strength | Yield strength | Elongation | Hardness |
| 517 | 310 | 28 | B75 |
Product forms
Hot and Cold-rolled wide strip, coil, sheet and plate, slit strip, cut sheets
We stock 436 hot and cold rolled stainless steel sheet, plate, strip and coil.
please welcome to contact us.
