UNS S17400 17-4PH 630 EN 1.4542 Hot Rolled Stainless Steel Round Bars

Guanglu is really a professional supplier, they always give us technical advice and provide good quality products with very competitive price!

—— Thomas Hoover

We received your goods last thursday and we are very pleased with the quality of your products.

—— Lionel Lobo

I'm Online Chat Now

UNS S17400 17-4PH 630 EN 1.4542 Hot Rolled Stainless Steel Round Bars

UNS S17400 17-4PH 630 EN 1.4542 Hot Rolled Stainless Steel Round Bars
UNS S17400 17-4PH 630 EN 1.4542 Hot Rolled Stainless Steel Round Bars UNS S17400 17-4PH 630 EN 1.4542 Hot Rolled Stainless Steel Round Bars UNS S17400 17-4PH 630 EN 1.4542 Hot Rolled Stainless Steel Round Bars

Large Image :  UNS S17400 17-4PH 630 EN 1.4542 Hot Rolled Stainless Steel Round Bars

Product Details:
Place of Origin: China
Brand Name: Daway
Certification: SGS
Model Number: 17-4PH, 1.4542, X5CrNiCuNb16-4, 630
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: negotiable
Packaging Details: seaworthy
Delivery Time: 15 days after receipt 30% of value
Payment Terms: T/T, L/C
Supply Ability: 200 tons per month
Detailed Product Description
Precipitation Hardening Stainless Steel: 17-4PH 630 EN 1.4542 Stainless Steel Round Bar Dia: 5.5~450mm, Others On Request
Delivery State: Solution Treated And Aged Surface: Black, Peeled Polished, Ground
High Light:

630 stainless steel

,

17 7 ph stainless steel

17-4PH 630 EN 1.4542 Hot Rolled Stainless Steel Round Bars


17-4PH is a chromium-nickel alloy that has a 4% copper additive, which enables it to be hardened

by very low-temperature heat treatments known as precipitation hardening.
The high percentages of chromium and nickel give this alloy excellent corrosion resistance,

physical properties, and a high level of strength at temperatures up to 800° F.

The major advantage of low temperature heat treatments is the elimination of distortion and scaling.
17-4PH has excellent mechanical properties and may easily be welded, deep drawn, forged,

and severely formed.



Chemical composition of grade 17-4PH stainless

Grade C Si Mn P S Cr Ni Cu Nb
17-4PH 0.07 1.00 1.00 0.040 0.030 15.0~17.5 3.0~5.0 3.0~5.0 0.15~0.45



Applications
This alloy is excellently suited for applications requiring high strength, good corrosion resist-ance

and good resistance to seizing and galling. 17-4PH finds extensive use in the aircraft and missile fields,

for motor shafts, instrument parts, gears, and etc.

Corrosion Resistance
The corrosion resistance of 17-4PH is slightly less-than-the superior resistance of the chro-mium-

nickel grades, but is somewhat higher than the straight chromium grades.
It possesses very good corrosion resistance against all atmospheric conditions.
Finish and heat treatment affect the level of corrosion resistance beneficially.



Product forms

17-4PH, 1.4542, X5CrNiCuNb16-4, 630 cold rolled stainless steel strip, coil, and sheet

17-4PH, 1.4542, X5CrNiCuNb16-4, 630 hot rolled stainless steel strip, coil and plate

17-4PH, 1.4542, X5CrNiCuNb16-4, 630 hot rolled stainless steel round bar

17-4PH, 1.4542, X5CrNiCuNb16-4, 630 cold drawn stainless steel wire rod, drawn wire

17-4PH, 1.4542, X5CrNiCuNb16-4, 630 hot forged stainless steel round bar, square bar, flat bar
